Sliding Door With Integrated Glass Railings
Slider with integrated railing offer a sleek and functional solution for homes and commercial spaces, especially those with space constraint residence, which do not have provision of balcony. This design combines the practicality of sliding windows with the safety and aesthetic appeal of a railing, creating a seamless and visually pleasing appearance.
Design Philosophy
- Safety: Prevent accidents and enhance security with integrated railing.
- Aesthetics: Elevate your space with a sleek and modern design.
- Functionality: Enjoy easy operation, ample ventilation, and energy efficiency.
- Versatility: Suitable for homes and commercial spaces alike.
- Space-Saving Solution: Create a functional balcony even in limited space.
Benefits
- Safety and Security: The integrated railing provides a secure barrier, preventing accidental falls and ensuring safety, especially for homes with children or pets.
- Seamless Integration: The railing is seamlessly incorporated into the window frame, creating a cohesive and visually appealing look.
- Enhanced Functionality: Sliding windows offer easy operation and ample ventilation, while the integrated railing provides a stable platform.
- Sleek Design: The seamless integration of the railing into the window frame creates a clean and modern aesthetic, enhancing the overall appearance of the space.
- Customization Options: These system fit various architectural styles and preferences, with options for different profile colours.
Application Area
- Residential spaces with space constraints where traditional balconies are not feasible.
- Apartments or high-rise buildings where safety and aesthetics are both priorities.
- Commercial spaces that require a modern, sleek look with safety features.
- Urban homes looking to create a functional balcony without extending the structure.
Key Features
Fixed Sash
To provide stability and support for the sliding sash.
Integrated Railing
For extra layer of Security
Sliding Sash
With smooth and effortless operation.
Ample Ventilation
Natural light, and fresh air
Functional Balcony
Create a functional balcony even in limited space
Technical
Information
Sash Height
1800-2400 mm
Sash Width
1800-2600 mm
Max Sash Weight
120 kg
Glass Railing Height
1050 kg
Glass Thickness
Railing: 13.52 mm
Construction Depth
76 mm
Bottom Threshold
43.3 mm
Frame Sightline
110 mm
Glass Thickness
Fixed Sash: 6 – 13.52mm
Sliding Sash: 5 – 30mm
Other Aluminium Windows
Blog
FAQs
While possible, the fixed + coupler setup increases cost, reduces aesthetics, and may cause discomfort when leaning on the profile. The integrated system solves all these issues.
Yes, 1050 mm is optimal for child safety and comfortable leaning for adults.
No, it must be installed at floor level to serve its railing function. Repositioning the handle isn’t feasible in this setup.
No, the handrail completes the glazing, covers bead & mullion joints, and serves as an elbow rest for users. It’s essential for both function and comfort.
As per current design, Pleated mesh over railing is not feasible.
The Sliding Door with Integrated Railings is a modern architectural solution that offers a sleek and functional design suitable for homes and commercial spaces. It combines the practicality of sliding windows with the safety and aesthetic appeal of a railing, resulting in a seamless and visually pleasing appearance.
The system is designed to provide safety and security by preventing accidents. It is often used in spaces with constraints or residences that lack a traditional balcony, allowing the creation of a functional balcony even in limited space.
Residential spaces with space constraints where traditional balconies are not feasible.
Urban homes looking to create a functional balcony without extending the structure.
Apartments or high-rise buildings where both safety and aesthetics are priorities.
Commercial spaces that require a modern, sleek look combined with necessary safety features.
The railing is seamlessly incorporated into the window frame, creating a cohesive and visually appealing look. It adds an extra layer of safety by acting as a secure barrier, which prevents accidental falls and ensures safety, particularly for homes with children or pets.
The system features a sliding sash with smooth and effortless operation. It is designed to maximize ventilation and daylight, providing ample ventilation, natural light, and fresh air. The system also utilizes a fixed sash to provide stability and support for the sliding sash.
Yes, the seamless integration of the railing into the window frame creates a clean and modern aesthetic. The system offers customization options, including various profile colors, to fit different architectural styles and preferences.
The available configurations (typologies) include:
1. Sliding Door with Integrated Railing with Left openable sash.
2. Sliding Door with Integrated Railing with Right openable sash.
The performance parameters include:
Sash Height: 1800mm to 2700mm.
Sash Width (system): 1800mm to 2600mm.
Maximum Sash Weight: 120 kg.
The fixed dimensions of the system include:
Glass Railing Height: 1050mm.
Construction Depth: 76mm.
Bottom Threshold: 43.3mm.
Frame Sightline: 110mm.
The glass components require specific thicknesses:
Railing Glass: 13.52mm.
Fixed Sash Glass: 6mm to 13.52mm.
Sliding Sash Glass: 5mm to 10mm.
The wind load performance depends on the type of sash used:
If a Reinforced Slider Sash is used, the system can handle up to 3000 Pa for most specified height and width combinations.
If a Normal Slider Sash is used, the performance is lower, with specific charts detailing the capacity based on sash height and width.
-
